WIZARD MS Dissolvable Frac Plug


WIZARD MS dissolvable frac plug is a revolutionary design with metal seal, bringing a better dissolution performance. WIZARD MS provides larger ID, shorter length, better pump-down ability, and a shorter total dissolution time. Without rubber component, the total dissolution time of WIZARD MS is shortened by 40%, and the pressure rating increases to 15,000psi with robust metal seal component introduced.



Features


· Better dissolution and pressure holding performance with metal seal.
· Better pump-down ability with compact design
· Big-ID up to 2.36”, 50% larger
· Ultra-short length, 60% shorter
· Suitable for low – high temperature applications 86°F  ~ 320°F
· Pressure rating up to 15,000 psi
· Running with standard Baker wireline or hydraulic setting tools


Specification

Temperature Rating 86°F ~ 320°F
Pressure Rating 15,000 psi
Casing Size 3.5” 4.5” 5” 5.5” 6”(Available upon request)
Weight (lb/ft) 11.6-15.1 23.2-24.1 17, 20-23, 26-26.8 24.5
Casing Grade N80 P110 Q125 140V
