Wizard Ultra Dissolvable Plug

Designed to withstand extreme conditions of high pressure and high temperature (HPHT), rating up to 15,000 psi and 350°F above. These frac plugs may also feature unique geometries and surface treatments, such as enhanced coatings or textures, that improve their performance and durability under corrosive and acidic environments.


Features

· Temperature rating up to 350°F

· Pressure rating up to 15,000 psi

· Acid frac & proppant frac application

· Coated variant available

· Ball-in-place and ball-drop convertible

· Run with standard Baker wireline or hydraulic setting tools

Specification

Temperature Rating

350°F and above

Pressure Rating

15,000psi

Casing Size (")

3.5 / 4.5 / 5 / 5.5 / 6" (Available upon request)

Casing Weight (lb/ft)

9.2 / 11.6-15.1 / 18.0-24.2 / 17.0-23.0, 26.0-26.8 / 23.2-24.5 lb/ft

Casing Grade

N80 P110 Q125 140V
